HPE 12904E v2 Main Processing Unit
Formát 1U / Hmotnost 2800 g / Šířka 201 mm / Výška 41 mm / Hloubka 411 mm / Vnitřní paměť 8000 MB
Všechny parametryKód: JH668A Výrobce: HPE EAN: 0190017141978
Popis
The HPE Networking Comware Switch Series 12900E is a next-generation modular data center core switch designed to support virtualized data centers and the evolving needs of private and public cloud deployments. It offers unprecedented levels of performance, buffering, scale, and availability with high-density 1GbE, 10GbE, 40GbE,100GbE and 400GbE connectivity. The switch series includes 1-, 2-, 4-, 8- and 16-slot chassis. Ready for software-defined networking (SDN), the HPE Networking Comware Switch Series 12900E supports a full Layer 2 and Layer 3 feature set as well as advanced data center features to build resilient scalable fabrics and deliver outstanding convergence times.
What is new supporting point:
Introducing next-generation, high performance 400G/100G H2 modules with improved features ideal for Telco, Cloud Service Providers and large enterprises
High density 10GbE, 40GbE, 100GbE and 400GbE connectivity with nonblocking wirespeed performance. (H2 modules supports 100GbE/400GbE with OS-Comware v9)
New generation OS-Comware v9 available with H2 modules offers enhanced software features such as segment routing MPLS, egress ACL, egress rate limiting and others for highly distributed environments
HB/HF, Type X and H2 modules support the same chassis, fan tray and power supply resulting in investment protection for customer
Nonblocking, lossless Clos architecture
VXLAN, EVPN, IRF, and DRNI support for virtualized and cloud deployments
What is new supporting point:
Introducing next-generation, high performance 400G/100G H2 modules with improved features ideal for Telco, Cloud Service Providers and large enterprises
High density 10GbE, 40GbE, 100GbE and 400GbE connectivity with nonblocking wirespeed performance. (H2 modules supports 100GbE/400GbE with OS-Comware v9)
New generation OS-Comware v9 available with H2 modules offers enhanced software features such as segment routing MPLS, egress ACL, egress rate limiting and others for highly distributed environments
HB/HF, Type X and H2 modules support the same chassis, fan tray and power supply resulting in investment protection for customer
Nonblocking, lossless Clos architecture
VXLAN, EVPN, IRF, and DRNI support for virtualized and cloud deployments
Parametry
| Formát | 1U |
|---|---|
| Hmotnost | 2800 g |
| Šířka | 201 mm |
| Výška | 41 mm |
| Hloubka | 411 mm |
| Vnitřní paměť | 8000 MB |
| Vstupní střídavé napětí | 100 - 240 V |
| Typ vnitřní paměti | DDR2 |
| Hmotnost (imperiální jednotky) | 6.2 lbs |
| Základní frekvence procesoru | 1200 MHz |
| Přepínací kapacita | 184000 Gbit/s |
| Montáž do racku | Ano |
| Kód harmonizovaného systému | 85176990 |
| Tabulka MAC adres | 16384 entries |
| Rozměry (š x h x v) | 201 x 411 x 41 mm |
| Vstupně-výstupní porty | 16 I/O module slots, maximum; Supports a maximum of 768 40GbE, 768 10GbE, 1/10GbE copper, 1/10GbE fiber, 1GbE fiber, or 10/100/1000 ports, or 576 100GbE ports, or a combination |
| Propustnost | 92100 Mpps |
| Flash paměť | 1024 MB |
| Vestavěný procesor | Ano |
| Směrovací protokoly | BGP4,IS-IS,MPLS,OSPF,OSPFv3,RIP,RIPng |
| Poznámka ke spotřebě energie | Power output: 2400W |
| Rozměry (Š x H x V) (imperiální jednotky) | 7.9 x 16.2 x 1.6 " |
| Správa výkonu | IMC - Intelligent Management Center; Command-line interface; Out-of-band management (serial RS-232C); SNMP manager; Telnet; Terminal interface (serial RS-232C); Modem interface; IEEE 802.3 Ethernet MIB; Ethernet interface MIB |
| Paměť a procesor | Quad Core MIPS64 at 1.2 GHz, 1 GB flash, 8 GB DDR2 SDRAM |
| Vstupní napětí DC | 48 - 60 V |
| Latence | Low latency under 5 microsecond latency (64-byte packets) |
| Poznámka k napájecímu zdroji | 16 power supply slots 1 minimum power supply required (ordered separately) |
