Newland FR4080 KOI II 2D MEGA Pixel/CMOS Omni Scanner W/ 2 M RRS232
search
  • Newland FR4080 KOI II 2D MEGA Pixel/CMOS Omni Scanner W/ 2 M RRS232

Newland FR4080 KOI II 2D MEGA Pixel/CMOS Omni Scanner W/ 2 M RRS232

3 971 Kč
S DPH

Momentálně nedostupné

Kód: NLSFR408028

  • Technologie propojení: Drátové
  • Délka kabelu: 2 m
  • Barva: Černá
  • Typ: Fixed bar code reader
  • Certifikace: FCC Part15 Class B, CE EMC Class B
  • Stupeň krytí IP: IP52
Všechny parametry
1D/2D, LED, RS232, 83 x 81 x 148 mm, 239 g, Black

Popis

As the first megapixel scanner on the market, the Koi reads 1D and 2D barcodes, including Aztec, with speed and ease. Equipped with a switch to toggle between paper and screen modes you are assured to have the best optimized reading every time.

The first megapixel presentation scanner on the market.
With user friendliness being at the forefront of POS systems, the FR40 Koi features soft illumination with a 10-degree tilt that insures comfort for both employees and customers. Combined with its superior performance and level of comfort, theFR40 Koi is the perfect addition to any POS system.

First megapixel presentation scanner.
At the top of the line, the FR40 Koi reads 1D and 2D barcodes, including Aztec, with speed and accuracy. It is the first presentation scanner on the market that includes a megapixel camera and is capable of reading even the most complex codes. This makes it the perfect solution for applications like POS systems in retail and pharmacy, ticket verification and more.

Unmatched flexibility.
With a switch to toggle between paper and screen mode, the FR40 Koi is ready for any barcode that it is presented with. This added flexibility, leaves this hardware unaffected.

Comfortable Illumination.
With a 10° angle and soft illumination, the FR40 Koi guarantees comfort to both customers and employees. When facing outwards, the illumination will not draw unnecessary attention.

IP52 rated sealing.
With an IP52 rated seal, the FR40 Koi is protected against dust, water and other contaminants.

1.2 drop resistance.
The FR40 Koi withstands multiple 1.2m drops to concrete (six sides, one drop per side).

IR trigger.
The IR sensor in the FR40 Koi enables the speedy capture of any barcode presented to it, markedly increasing output and productivity.

2D Mega Pixel CMOS Omnidirectional presentation desktop scanner with 2 meter RRS232 cable and multi plug adapter.

Parametry

Technologie propojeníDrátové
Délka kabelu2 m
BarvaČerná
TypFixed bar code reader
CertifikaceFCC Part15 Class B, CE EMC Class B
Stupeň krytí IPIP52
Hmotnost293 g
Šířka83 mm
Typ senzoruCMOS
Výška148 mm
Hloubka81 mm
Svislý pozorovací úhel-45 - 45 °
Typ zdrojeAC
Provozní rozsah teplot (T-T)-20 - 60 °C
Rozsah teplot při skladování (T-T)-40 - 70 °C
Doporučená provozní relativní vlhkost5 - 95 %
Dodávané kabelyRS-232
Ochranné funkceDrop proof,Electrostatic Discharge (ESD) protection
Vstupní napětí5 V
LED indikátoryAno
Typ skeneru1D/2D
Spotřeba elektrické energie219 mA
Standardní rozhraníRS-232
Podpora 2D čárových kódů (matice a stohované)Aztec Code,Data Matrix,Micro QR Code,PDF417,QR Code
BzučákAno
Externí napájecí adaptérAno
Rozlišení optického senzoru (Š x V)1280 x 800 pixels
Podporované lineární (1D) čárové kódyCodabar,Code 11,Code 128,Code 39,Code 93,EAN-13,EAN-8,GS1 DataBar,ISBN,ISSN,ITF-14,ITF-6,Industrial 2 of 5,Interleaved 2 of 5,MSI,Matrix 2 of 5,Plessey,UPC-A,UPC-E
Úhel čtení při náklonu-50 - 50 °
Úhel odklonu snímání0 - 360 °
Kontrast tisku25 %
