HPE Aruba AP-565EX (RW) OTDR Stock/.
Technologie propojení Zigbee / Barva Bílá / Certifikace CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance certified 802.11a/b/g/n/ Wi-Fi Alliance certified Wi-Fi 6 (802.11ax) Wi-Fi CERTIFIED ac (with wave 2 features) Wi-Fi CERTIFIED Location Class 1 Division 2 certified ATEX Zone 2 certified / Hmotnost 1030 g / Šířka 165 mm / Výška 165 mm
Všechny parametryKód: R4W62A Výrobce: HPE EAN: 0190017447810
Popis
HPE Aruba Networking 560EX Series Hazardous Location Access Points provide cost-effective Wi-Fi 6 connectivity for outdoor hazardous locations like oil fields and rigs, mining facilities, and environments with explosive atmospheres and vapors that need Class 1 Division 2 or ATEX Zone 2 solutions. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the 560EX series delivers the speed and reliability needed to bring Wi-Fi to hazardous locations. These Wi-Fi 6 outdoor access points (APs) are purpose-built for hazardous locations and can be quickly deployed using zero touch provisioning (ZTP). HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs. AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 560EX series includes a limited lifetime warranty.
What is new supporting point:
Class 1 Division 2 and ATEX Zone 2 certified outdoor Wi-Fi 6 APs provide up to 1.49 Gbps maximum aggregate data rate
Internet of Things (IoT)-ready with a built-in Bluetooth 5 and 802.15.4 radio that supports Zigbee
Dynamic segmentation and policy enforcement firewalls (PEF) automatically enforces consistent policies across every network, keeping users and devices secure
It is purpose built for hazardous locations and to survive in one of the harshest outdoor environments and extreme temperatures (-40˚C to +55˚C)
It has client and RF optimization to match clients with the top available AP and reduce coverage gaps
What is new supporting point:
Class 1 Division 2 and ATEX Zone 2 certified outdoor Wi-Fi 6 APs provide up to 1.49 Gbps maximum aggregate data rate
Internet of Things (IoT)-ready with a built-in Bluetooth 5 and 802.15.4 radio that supports Zigbee
Dynamic segmentation and policy enforcement firewalls (PEF) automatically enforces consistent policies across every network, keeping users and devices secure
It is purpose built for hazardous locations and to survive in one of the harshest outdoor environments and extreme temperatures (-40˚C to +55˚C)
It has client and RF optimization to match clients with the top available AP and reduce coverage gaps
Parametry
| Technologie propojení | Zigbee |
|---|---|
| Barva | Bílá |
| Certifikace | CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance certified 802.11a/b/g/n/ Wi-Fi Alliance certified Wi-Fi 6 (802.11ax) Wi-Fi CERTIFIED ac (with wave 2 features) Wi-Fi CERTIFIED Location Class 1 Division 2 certified ATEX Zone 2 certified |
| Hmotnost | 1030 g |
| Šířka | 165 mm |
| Výška | 165 mm |
| Hloubka | 130 mm |
| Bluetooth | Ano |
| Síťové standardy | IEEE 802.11ax,IEEE 802.11mc |
| Počet portů Ethernetu (RJ-45) | 1 |
| Provozní rozsah teplot (T-T) | -40 - 55 °C |
| Doporučená provozní relativní vlhkost | 5 - 95 % |
| Typ napájení | 802.3at |
| Certifikáty shody | Federální komunikační komise (FCC), ISED, CE, Elektromagnetická kompatibilita (EMC), Směrnice pro nízké napětí (LVD) |
| Účel | Venkovní |
| Záruční doba | Doživotní |
| Verze Bluetooth | 5.0 |
| Počet portů USB 2.0 | 0 |
| Platforma | HPE Aruba Networking |
| Přenosová rychlost sítě Ethernet | 1000 Mbit/s |
| Standardy Wi-Fi | Wi-Fi 6 (802.11ax) |
| Umístění | Strop, Zeď |
| Typ antény | Vnitřní |
| Doporučené použití | Venkovní |
| Tlačítko reset | Ano |
| Power over Ethernet (PoE) | Ano |
| MIMO | 2 x 2 |
| Hmotnost (imperiální jednotky) | 2.27 lbs |
| 5 GHz | Ano |
| Typ směrovosti antény | Všesměrová |
| Montáž | Na strop |
| Podpora MACsec | Ne |
| Kompatibilní operační systémy | HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8.7.1.0; HPE Aruba Networking Wireless Operating System 10 |
| Počet antén | 3 |
| Spotřeba energie (maximální) | 15.6 W |
| Vstupně-výstupní porty | E0: 10/100/1000BASE-T (RJ-45) USB-C console interface |
| MU-MIMO | Ano |
| Počet SFP portů | Bez |
| Frekvenční pásmo | 20/40 (2.4 GHz), 20/40/80 (5 GHz), peak data rate 1.49 Gbps, maximum data rate 1.78 Gbps GHz |
| Pásmo 2,4 GHz | Ano |
| Maximální přenosová rychlost (2,4 GHz) | 574 Mbit/s |
| Typy PoE | PoE-In (pouze) |
| 6GHz MIMO | Bez |
| Porty | USB-A |
| Přenosová rychlost - 2,4 GHz | 574 |
| Přenosová rychlost - 5 GHz | 1201 |
| Přenosová rychlost - 6 GHz | Bez |
| 5GHz MIMO | 2 x 2 |
| Maximální rychlost LAN | 1G |
| Maximální rychlost SFP | Bez |
| Maximální zisk antény | 5.4 dBi |
| Správa přístupových bodů | On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service |
