TRENDnet 10GBASE-LR SFP+ Multi-Mode/LC Module 400M With DDM
Hmotnost 22 g / Šířka 14.8 mm / Výška 11.85 mm / Hloubka 56.5 mm / Síťové standardy IEEE 802.3ae / Provozní rozsah teplot (T-T) 0 - 70 °C
Všechny parametryKód: TEG10GBSR Výrobce: TRENDnet EAN: 0710931140170
Popis
TRENDnet’s hot-pluggable TEG-10GBSR, 10GBASE-SR SFP+ Multi Mode LC Module, works with a MSA compliant SFP+ slot. This Multi Mode transceiver spans distances up to 550 meters (1,804 feet), comes with a LC duplex connector, and supports up to 10.5 Gbps networking throughput speeds. Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage.
Hot-Pluggable SFP+
Hot-pluggable SFP+ transceiver works with a MSA compliant SFP+ slot
Fiber Wavelength
Compatible with Multi Mode 850 nm transmissions
Fiber Distance
Supports networking for distances up to 550 meters (1,804 feet)
Fiber Port
LC-type duplex connector
DDM Support
Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage
Power Supply
Single 3.3 volt power supply
Operating Temperature
Rated for an operating temperature range of 0 to 70 °C (32 to 158 °F)
Standards
Compliant with SFF-8431, SFF-8432, SFF-8472, FC-PI-4,10G FC, and IEEE802.3ae 10GBASE-SR
Hot-Pluggable SFP+
Hot-pluggable SFP+ transceiver works with a MSA compliant SFP+ slot
Fiber Wavelength
Compatible with Multi Mode 850 nm transmissions
Fiber Distance
Supports networking for distances up to 550 meters (1,804 feet)
Fiber Port
LC-type duplex connector
DDM Support
Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/receive power, temperature, and voltage
Power Supply
Single 3.3 volt power supply
Operating Temperature
Rated for an operating temperature range of 0 to 70 °C (32 to 158 °F)
Standards
Compliant with SFF-8431, SFF-8432, SFF-8472, FC-PI-4,10G FC, and IEEE802.3ae 10GBASE-SR
Parametry
| Hmotnost | 22 g |
|---|---|
| Šířka | 14.8 mm |
| Výška | 11.85 mm |
| Hloubka | 56.5 mm |
| Síťové standardy | IEEE 802.3ae |
| Provozní rozsah teplot (T-T) | 0 - 70 °C |
| Doporučená provozní relativní vlhkost | 0 - 95 % |
| Maximální přenosová vzdálenost | 550 m |
| Maximální přenosová rychlost | 10000 Mbit/s |
| Vlnová délka | 850 nm |
| Spotřeba energie (typická) | 0.439 W |
| Optický konektor | LC |
| Typ rozhraní | SFP+ |
| Typ transceiveru SFP | Optický |
| Podpora multimódového optického vlákna (MMF) | Ano |
| Kód harmonizovaného systému | 85369010 |
| Počet optických portů | 1 |
| Standard transceiveru SFP | SR |
| Podpora Hot-Plug | Ano |
