HPE Aruba AP-655 (US) -Stock/.
Barva Bílá / Certifikace UL2043 plenum rating Wi‐Fi Alliance Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2, and WPA3 -Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE / Hmotnost 1800 g / Šířka 260 mm / Výška 260 mm / Hloubka 56 mm
Všechny parametryKód: R7J39A Výrobce: HPE
Popis
The HPE Aruba Networking 650 Series Campus Access Points are our flagship Wi-Fi 6E access points (APs) that take advantage of the 6 GHz band for greater capacity, wider channels, and interference-free spectrum. Designed to meet the demands of bandwidth-hungry video, a growing numbers of client and Internet of Things (IoT) devices, and the growth of cloud services, these high-performance Wi-Fi 6E APs provide comprehensive tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 7.8 Gbps combined aggregate data rate. The 650 series includes ultra tri-band (UTB) filtering to help minimize channel interference and dual configurable 5 Gbps Ethernet ports to mitigate coverage gaps, provide greater resiliency, and deliver fast, secure connectivity. Up to seven 160 MHz channels in 6 GHz support low-latency, bandwidth-hungry applications such as high-definition video and AR/VR applications. The 650 series includes a limited lifetime warranty.
What is new supporting point:
Built-in GPS receivers and intelligent software enable APs to self-locate and act as reference points for more accurate indoor location measurements
Flagship Wi-Fi 6E APs provide tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 7.8 Gbps combined aggregate data rate
4x4 MIMO radios to deliver peak performance and increased capacity using multi-user (MU-MIMO) and orthogonal frequency-division multiple access (OFDMA) (uplink and downlink for both)
Patented UTB filtering enhances the use of 5 GHz and 6 GHz bands
High availability with dual 5 Gbps wired ports for redundant Ethernet and power
IoT-ready with support for Bluetooth Low Energy (BLE) and Zigbee
What is new supporting point:
Built-in GPS receivers and intelligent software enable APs to self-locate and act as reference points for more accurate indoor location measurements
Flagship Wi-Fi 6E APs provide tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 7.8 Gbps combined aggregate data rate
4x4 MIMO radios to deliver peak performance and increased capacity using multi-user (MU-MIMO) and orthogonal frequency-division multiple access (OFDMA) (uplink and downlink for both)
Patented UTB filtering enhances the use of 5 GHz and 6 GHz bands
High availability with dual 5 Gbps wired ports for redundant Ethernet and power
IoT-ready with support for Bluetooth Low Energy (BLE) and Zigbee
Parametry
| Barva | Bílá |
|---|---|
| Certifikace | UL2043 plenum rating Wi‐Fi Alliance Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2, and WPA3 -Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE |
| Hmotnost | 1800 g |
| Šířka | 260 mm |
| Výška | 260 mm |
| Hloubka | 56 mm |
| Bluetooth | Ano |
| Síťové standardy | IEEE 802.11ax,IEEE 802.11mc |
| Počet portů Ethernetu (RJ-45) | 2 |
| Slot pro zámek | Ano |
| Typ zámku kabelu | Kensington |
| Certifikáty shody | Federální komunikační komise (FCC), ISED, CE, Směrnice pro nízké napětí (LVD) |
| Verze Bluetooth | 5.0 |
| Počet portů USB 2.0 | 1 |
| Přenosová rychlost sítě Ethernet | 5000 Mbit/s |
| Maximální přenosová rychlost | 7800 Mbit/s |
| Bluetooth Low Energy (BLE) | Ano |
| Umístění | Ceiling |
| Typ antény | Vnitřní |
| Doporučené použití | Kancelář |
| Power over Ethernet (PoE) | Ano |
| DC-in konektor | Ano |
| MIMO | Ano |
| Hmotnost (imperiální jednotky) | 3.97 lbs |
| 5 GHz | Ano |
| 6 GHz | Ano |
| Typ směrovosti antény | Všesměrová |
| Podpora MACsec | Ne |
| Kompatibilní operační systémy | AP-654 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-654 (including 6 GHz support): HPE Aruba Networking Wireless Operatin |
| Počet antén | 4 |
| Bezpečnostní algoritmy | WPA,WPA2,WPA3 |
| Vstupně-výstupní porty | Ports E0, E1: Ethernet wired network ports (RJ-45) U0: USB 2.0 host interface (Type A connector) Kensington security slot Serial console interface (proprietary, micro B USB physical jack) |
| Podpora QoS | Ano |
| Frekvenční pásmo | 20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 7.8 Gbps GHz |
| Pásmo 2,4 GHz | Ano |
| Band steering | Ano |
| Cloudové řízení | Ano |
| Vlastnosti antény | Integrated antenna |
| Wi-Fi Multimedia (WMM)/(WME) | Ano |
| Správa přístupových bodů | On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service |
| Prostorové datové toky | 4 |
| Počet vnitřních portů RJ-45 | 2 |
